UWatch U8 Pro comes with a 1.48 inch color TFT LCD display with Bluetooth, multi-language support and a 230 mAh battery. In order to function fully, the device can be connected to an iOS or an. Aosmart U8 Bluetooth Smart Watch Conveniently take control of your health using this watch for features such as; Sleep monitor, Step counter, Drink Water Reminder & more! This watch is 100% compatible with Android smart phones. Connect the SmartWatch u8 via the USB cable to your computer. Once the Windows starts detecting the device, we could indicate what driver should be installed; go inside the folder, then click the folder (DriverW2000XP). SMART WATCH USER GUIDE General Set-Up & App Where can I find how-to videos and tutorials on using my device? Check out the videos here. WHICH PHONES ARE COMPATIBLE WITH MY HYBRID SMARTWATCH? Your hybrid smartwatch is compatible with Android(TM) phones and iPhone(R), specifically with Android OS 4.4 or higher, iOS 8.1/iPhone 5 and above.

Recently, we presented the most economical Smartwatch in the market, the Smartwatch u8, but we weren’t explained about how to update the software, that is essential. You should do this before updating the firmware of Smartwatch U8 :

  • It is recommended to disable the antivirus software to run all of the tools that needed to flash the smart watch correctly.
  • It is recommended to upgrade the firmware to Windows 7.


Step by step :

Downloads
  1. Download the FlashTool, drivers and the firmware (password : geekbuying.com)(thanks for the uploader). If unsuccessful, other download link at the bottom of the article.
  2. Flashtool is used to flash the SmartWatch u8 and the other devices. The file also has everything else that needed to update the clock, including the latest firmware.
  3. Install the drivers. If you do it on Windows 7, you could install the driver directly. It has been provided in the downloaded files (Driver_Windows_7-Vista / InstallDriver.exe or 64-bit). If you use Windows XP or Windows 2000, the driver has to be manually installed, you can follow the steps here :
  4. Connect the SmartWatch u8 via the USB cable to your computer.
  5. Once the Windows starts detecting the device, we could indicate what driver should be installed; go inside the folder, then click the folder (Driver_W2000_XP).
  6. Once the installation finished, please unplug the clock on your computer. To verify that the drivers have been properly installed, just see if the computer recognizes your.
  7. In the downloaded file there are three firmwares, the FN1_V004 version, and FN1-2.V008 FN1-1.V008 version are available. You can install it if you want, but the latest firmware is the FN1-2.V008. Once you executed the Flashtool, you should check in the Download Agent MTK_AllInOne_DA.bin whether it is loaded, otherwise you should look for the file in the FlashTool folder by clicking on the “Donwload Agent” button. Scatter File In the line that we already introduce the configuration file, the firmware that you want to install, clicking on the “Scatter / Config File” button. In our case, M28_Firmware_FN1-2.V008 / OVIPHONE60M_11B_BB.cfg. Once we load the configuration file will be added in the middle part of flashtool the other four files firmware.
  8. You can begin flashing your SmartWatch U8, check the SmartWatch ( it should be off ), and connect the computer using the USB cable. Then click on the Download button, and if the PC recognizes it, the intelligent clock will begin to flash your device. During the process, do not touch anything on the clock, or close the FlashTool, or disconnect the USB.

Once the flashing process is finished, FlashTool will display a message and we can disconnect the USB. Watch and enjoy yuor new firmware.

Another firmware download link:


https://www.mediafire.com/?8x7ht9jpy3fyfxz,

https://mega.co.nz/#!HlQVgCLD!y3kQYrl7zyA8EVe1xl-Fr9zBO78KaQqZ8y_gQNdelgk,

http://www.mediafire.com/download/0by7xe5x2lweyyg/smartwatch-u8-actualizado.zip

Caution: Please do not update firmware unless you know what you are doing. Firmware updates may occasionally have bad results. The firmware update process is done entirely at your own risk. Before attempting to update the firmware, back up your data.

Thanks for the uploader.

SmartWatch U8
Previous ArticleNext Article

03-04-2017, 03:23 PM

This guide will explain how to flash a firmware / ROM (in scatter format) to a Mediatek (MTK) Smartwatch using FlashTool .

Requirements

Kor Audio Smartwatch U8Kor Audio Smartwatch U8
  • Download smartwatch FlashTool
  • Install Mediatek VCOM drivers for MTK Smartwatches
  • Take out the Smartwatch's battery > Hold the Power button then connect to PC via USB > Wait till the MTK USB driver is done installing > Reinsert the battery
  • Download the Smartwatch's stock ROM / firmware (must be in scatter format, not .bin)

Steps to flash a Mediatek Smartwatch using FlashTool


Follow the steps below to flash a Mediatek smartwatch using Flashtool

See the video tutorial below or @ https://youtu.be/NIgRVo_Wd8k
  1. Launch Flash_tool.exe as Administrator
  2. Click Scatter / Config file
  3. In the Window that pops up, navigate to the firmware folder, highlight the scatter / config file then click Open
  4. The available files (in the firmware) should be listed and ticked in FlashTool. Tick whichever partition(s) you wish to flash to the Smartwatch then click Download (with an arrow above it)
  5. Stop should now be Red in color. Power off the Smartwatch and connect it to PC via USB (with battery inside and without holding the Power button)
  6. The Smartwatch should get detected by FlashTool with a Red loading bar (Download DA)
  7. Flashing should continue with a Yellow bar (Pre-format code area)
  8. Flashing should continue with a Blue bar (Downloading software to flash)
  9. You should then see a green loading bar (Format
  10. flash)
  11. Once flashing is done, you should see a Green bar with 100% and a Green circle. You may close FlashTool, disconnect and power On the Smartwatch

Important Notice

U8 Smartwatch App For Android

  • Its recommended you backup your smartwatch's firmware (if you can) before flashing any firmware just in case the device gets bricked
  • You should only flash files / firmware for your smartwatch model. Doing otherwise could brick it
  • If the smartwatch merely shows a charging sign when you connect to PC for flashing then you've not installed the drivers correctly or the correct drivers. It could also indicate a faulty USB port

Kor Audio U8 Smart Watch


Video Transcript
Quote:With your firmware and driver in place, you navigate to the location where you have your SP Flash tool and you run it as Administrator. If prompted, you click Yes. Click on Choose in front of Scatter-loading. Navigate to the folder where you have your Smartwatch's firmware, select the scatter file then click Open. Now, we have the files loaded. Click Download, power off the Smartwatch & connect it to the PC still with battery inside, don't hold any button. We have detection and flashing should begin.
Flashing has begun. Its very important you do not interrupt this process. Once flashing is done, you should have your 100% OK prompt meaning SP Flash tool has successfully flashed the firmware to your smartwatch. That's how to flash firmware to a Mediatek Smartwatch using SP Flash tool

U8 Smartwatch App


Video Transcript
Kor audio u8 smart watch

U8 Smartwatch Code

Quote:In this video tutorial, I'm going to be explaining how to flash a Mediatek Smartwatch using FlashTool Its very important you understand that FlashTool is different from SP Flash Tool. I assume you've installed your smartwatch drivers and you have the firmware for your smartwatch. Now, run FlashTool as Administrator If you're not the admin, just double-click flash_tool. Now, you might get prompt just select Yes. and you hold on for the FlashTool dashboard to come up. You might get an error like this, just click OK If you have Download Agent empty, what you need to do is just click DownloadAgent at the top and then navigate to the FlashTool folder, selectMTK_AllInOne_DA.bin and then you click Open.
That will load the Download Agent Next up is scatter file. You click Scatter/Config file at the top. Navigate to the folder where you have the smartwatch's firmware. I'll flash the backup I'd made. Mine is in config format. That's the difference between FlashTool and SP Flash tool. For SP Flash tool, you'll usually have just in txt format but this has the config format ok? You might also have the scatter format but mostly. It also supports config format (to put it thus) The firmware for my smartwatch is in config format so I select the config file and click Open You can see I have my partitions loaded here.
To flash, you click Download, power off the smartwatch still with battery inside and don't hold any button, then you connect it to the PC via USB cord I'm going to do that just now. You can see its getting detected, I have downloading DA (red bar) [flashing] Its very important you do not interrupt this process. The last bar is going to be the green bar flashing was successful. That's basically how to flash a Mediatek Smartwatch using FlashTool
